AA4C 10T/ 15T Secondary vehicle maintenance and testing lane Roller brake tester with axle load side slip tester


1. Product Features:

  • The inspection tester supports a maximum axle load of  10,000/15,000 kg.
  • The detection control system uses a high-brightness LED display for guidance and is controlled by an industrial-grade computer.
  • Integrated with smoke density, exhaust gas, and headlight detection functions; speedometer detection functionality is optional.
  • The detection system supports manual single-station, semi-automatic, and fully automatic operation modes.
  • Automatically prints and determines detection results, with fast query capabilities for detection data and records based on time, license plate, vehicle model, etc.
  • Equipped with the latest national standards, allowing users to modify detection criteria as needed.
  • Features high-speed system signal data acquisition; the braking process curve can be dynamically displayed on the software interface while operating the brake pedal.

2. Operation Interface:

3. Vehicle Inspection Login Interface:


4. Detailed Technical Parameters for Each Inspection Tester:

(1) AA-FZ-10/15T Brake Tester Technical Parameters:

  • Rated Load (t): 10/15
  • Wheel Brake Force Measurement Range (daN): 0-4000
  • Division Value (daN): 1
  • Indication Error: ±3%
  • Roller Diameter (mm): 245
  • Roller Length (mm): 1100
  • Inner Span of Rollers (mm): 700
  • Outer Span of Rollers (mm): 2900
  • Roller Center Distance (mm): 470
  • Height Difference Between Front and Rear Rollers (mm): 30
  • Roller Surface Type: Sand-coated
  • Roller Sliding Friction Coefficient: ≥0.85
  • Roller Surface Linear Speed (Km/h): 2.5
  • Third Roller Status: Available
  • Auxiliary Vehicle Exit Device: Airbag lifting
  • Power Supply (V): AC380V 50Hz
  • Motor Power (KW): 11KW*2
  • Sensor Power Supply (V): DC12
  • Calibration Ratio: 10
  • Self-weight (Kg): 1800

(2)AA-CH-10/15 Side-Slip Test Platform Technical Parameters:

  • Model: CT-CH-10/15T
  • Rated Load (t): 10/15
  • Measurement Range (m/Km): ±10
  • Slide Plate Dimensions (mm): 1000*1100
  • Applicable Wheel Track (Inner/Outer) (mm): 700/2900
  • Relaxation Plate Dimensions (mm): 1100*250
  • Sensor Power Supply (V): DC12
  • Sensor Output Signal (V): 0-12
  • Structure Type: Double-plate linkage
  • Self-weight (t): 0.85
