Spray Booth AA-SB607(6.9m*4m*2.65m)

  • AA-SB607

Description

AA-SB607 Auto Paint Spraying/Baking Room is able to spray paint in all kinds of weather and automatically atconstant temperature.
Extra-thick Italy-made Filtering Cotton can block away 99 % of dusts and other granulesin the air to guarantee zero impurity of
paint coat in spraying.The air exchange as frequent as 256 times per hour in spraying drives out the contaminated air always keep
the internal air clean and refreshed and thus to do good to the workers health. In paint baking imported Burner is run for heating,
the high-efficiency heat exchanger produces all-descending hot airflow,and the whole auto paint-coat is dried up by low-temperature
complete drying without the troubles to dismantle the rubble parts and chairs of vehicles.The process is rational and well-considered
for simple handling . The paint-coat on every section of an auto can be dried up at the same speed,presenting smooth and shining
appearance when finished even without surface burnishing, In addition the Anti-overpressure Emergency device of the Emergency Exit
safeguards against internal overpressure to give you the absolute safety reliability.
1) 70mm thick flame-resistant and heat-preserving board for the body structure made by sandwitching two sheets of colored steel and
one piece of EPS (epispastic polystyrene);
2) Heat and shutt off at preset time Automatically;
3) Itaian Riello burner;
4) Even wind Inhaled and exhausted while painting; constant temperature kept while baking;
5) Components produced according to relevant standards thus easy assembly and durability;
6) Reliable Swiss made electrical air valve which can automatically shift its position to adjust the air volume when the painting phase
shift change baking;
7) Philips lights that provide even light hence a shadow-free environment with an illuminance up to 1100 Lux;
8) Lots of aluminum alloy for shape and stainless steel frame used to support the top filters hence an even more elegant style;
9) Imported stainless-steel heat exchanger of scientific design insures the preset temperature can be reached in several minutes.
10) Specially designed ventilator characterized by large air volume and low noise;
11) No-pump water curtain paint for mist filtering device that can reduce more than 98% of the fog without the troubleof replacing
drying-method filter by fully mixing fog, water and air, and ensures a qualified exhaust according to  the relevant state standards;
12) Anti-overpressure device that can automatically open the emergency exit when overpressure is sensed;
13) Dual temperature controllers including an electronic and a quality mechanical temperature controller that can give sound and light
alarms when the indoor temperature is above the specified value and automatically cut the power
14) Movable stainless steel racket attached for spraying small parts conveniently;
15) Selected equipments and materials to ensure a 20-year service life.

Outside Size (mm)

7040×5500×3450

Front Door(mm)

3000(w)×2600(H)

InsideSize(mm)

6900×4000×2650

Total Power(km)

30


Cabin System

Wallboard

EPS (epispastics polystyrene)Colorful Steel Skin Boards, 70mm Thick, Ceiling panel:50mm thick. The side door with a pressure lock which will automatically open when the pressure inside is over-pressure.

Basement

Full Grid, Adjustable Height, Galvanized Steel Sheet Construction, Three Embossed Steel Ramps

Air Circulation System

Inlet Fan

Model:YDW 4.5L1

Outlet Fan

Model:4-82-6.3E

Capacity:24000m3/h

capacity:30000m3/h

Pressure:800Pa

Pressure:1236Pa

Power:4kw

Power:15kw

Quantity:2 sets

Quantity:1set

The circulation system covers a set of automatic valve and two sets of manual valve. Manual adjustment valves are placed in inhaling and exhaust duct to control airflow volume and adjust pressure. A stainless steel trapezoid hood and a stainless cone hood

Purification System

Dual Filtering Structure, The Primay Filter Can Capture Granules Larger than 10μm. Ceiling Filter Capture Granules Bigger than 4μm.Its filtering rate reaches 98%. air pressure balance gauge, TSP≤1.2mg/m3

Heating System

Burner

Italy Riello Brand, RG5S Diesel Burner, 260000Kcal/h, 20N Damp Motor 2 sets quick dryer.

Heat Energy Converter

SUS304 Stainless Steel heat exchanger, argon arc welding, heat exchange rate 85%;

Max Temp:80。C, Heating Time:4-6min(20-60℃), Fuel Consumption: 6-8kg/vehicle

Light System

Ceiling Light: 32 pcs 36w Philips Lamp; Bottom Light: 32 pcs 20w Philips Lamp, 1100 Lux

Controlling System

PLC controlling, soft touching button, Spray & Baking Switch, Light Switch, Emergency Stop, Breakdown Alarm, Failure alarm, timer

Environmental System

No-pump water curtain for mist filtering device can reduce more than 98% of the fog without the trouble of replacing drying-method filter by fully mixing fog, water and air, and ensure a qualified exhaust according to the relevant state standards
